ALLEGRO SPORT ALLEGRO SPORT ALLEGRO SPORT

ALLEGRO SPORT

OVERVIEW


ALLEGRO COMP

Price¥95,000(本体価格)

  • Size 14",16" (Femme) / 15",17",19"
  • Frame 6061 aluminum
  • Fork Redesigned chromoly straight blade unicrown
  • Rear Derailleur Shimano Acera RD-M360
  • Crank Shimano FC-M171triple
  • Wheels Alex DC26 double wall alloy rims, 32H
  • SST
  • ATS
  • Femme

SPECIFICATIONS


Model ALLEGRO SPORT
Price ¥65,000
Frame 6061 aluminum with hydro-formed top and down tube, taper gauge "S" bend stays, replaceable derailleur hanger and fender/rack mount eyelets
Fork Redesigned chromoly straight blade unicrown with bulge butted chromoly steerer,low-rider carrier mounts and forged dropout with fender mount eyelets
Headset FSA Integrated IS threadless, 1 1/8"
Wheels Alex DC26 double wall alloy rims, 32H, Formula alloy hubs with QR and 14g stainless steel spokes
Tires Vittoria Randonneur with Double Shield puncture protection and reflective sidewalls, 700 x 32c
Derailleurs Shimano Acera RD-M360 rear and Shimano FD-M191 bottom pull front
Shift levers Shimano Rapidfire ST-M310, 24-Speed
Chain KMC Z7
Cassette SRAM PG 820 8-Speed 11-32T
Crankset Shimano FC-M171, 48/38/28T, 170mm(14/16,15-17), 175mm (19").
BB Set FSA sealed cartridge, 68 x 110.5mm
Pedals Comfort platform style with TPE non-slip insert
Brakeset Tektro RX-1.0 linear-pull with front power modulator and Shimano brake levers
Handlebar Jamis flatbar,6061T-6 aluminum,31.8x10° sweep x680mm
Stem Jamis Trekking, 3D forged alloy, 10° rise x 90mm (14/16,15/17), 110mm (19)
Grips Anatomic double density kraton grip with end plug
Seat Post Jamis alloy micro-adjust, 27.2 x 350mm, alloy clamp with QR seatpin
Saddle Jamis Touring with SL cover / Jamis Touring Femme with SL top"
Sizes 14",16",15",17",19"
Color Gloss Black, Orange Crush or Teal Fo' Real
Weight 11.6kg

※水色表記はFEMME MODEL

FIT & SIZING


ジオメトリ表
  • A = SEAT TUBE
  • B = EFFECTIVE TT LENGTH
  • C = HEAD TUBE ANGLE
  • D = SEAT TUBE ANGLE
  • E = CHAINSTAY
  • F = WHEELBASE
  • G = FORK RAKE
  • H = BOTTOM BRACKET DROP/HEIGHT
  • I = HEAD TUBE
  • J = STANDOVER
  • K = STACK
  • L = REACH
MODEL ALLEGRO COMP
SIZE 15 17 19
inch inch inch
ASEAT TUBE 371 408 459
BEFFECTIVE TT LENGTH 545 560 570
CHEAD ANGLE 71° 71° 72°
DSEAT ANGLE 74° 74° 73.5°
ECHAIN STAY 435 435 435
FWHEEL BASE 1040 1056 1052
GFORK RAKE 50 50 50
HBB DROP 55 55 55
IHEAD TUBE 135 150 175
JSTAND OVER 733 760 799
KSTACK 545 559 586
LREACH 387 398 395
REAR OLD 130 130 130
MODEL ALLEGRO SPORT FEMME
SIZE 14 16
cm cm
ASEAT TUBE 335 372
BEFFECTIVE TT LENGTH 520 530
CHEAD ANGLE 70.5° 71°
DSEAT ANGLE 74.5° 74 °
ECHAIN STAY 435 435
FWHEEL BASE 1024 1025
GFORK RAKE 50 50
HBB DROP 55 55
IHEAD TUBE 125 135
JSTAND OVER 721 733
KSTACK 533 545
LREACH 370 372
REAR OLD 130 130
